SPECIFICATIONS



AI Functions: Motion Detection



Brand Name: GENIUSPY

Certification: CE

Color: black

Color Night Vision: no

Connectivity: IP/Network Wired

High Definition: 4.0 Megapixels

High-concerned chemical: none

IP Rating: IP68

IR Distance(m): 5-10m

Installation: Ceiling

Lens (mm): 2MM

Lens Quantity: Single Lens

Megapixels: 4MP

Model Number: GS-SVN1CMR/GS-SVN1C4MR

Operating Temperature: -10°-60°

Power Consumption(W): 1.8w

Power Mode: Mains Electricity

Power Supply: With Poe

Power Supply(V): 12v

Rechargeable Battery: NONE

Scene: Indoor and outdoor

Sensor: CMOS

Shell Material: Metal

Style: Mini Camera

Supported Mobile Systems: Android,iOS

Supported Operating Systems: Windows Vista,Windows 7,macOS,Windows 8,Windows 10,Windows 2000,Windows 2008,Windows 2003

Video Compression Format: H.264,H.265

Viewing Angle : 120°

Zoom: NONE

Zoom type: none



4MP 2MP Wide Angle view 120degree IP68 Waterproof Underwater outdoor IR Night Vision Mini Vehicle IP Camera For Car &Bird Nest

Notice :



2MP H.264 Only  -- camera is 1080p 2mp video output only support H.264 Formate,



4MP 3MP 2MP H.265 H.264---camera is  4MP HD , video output only support H.264 /H.265 Formate





it fully competabile with hikvision nvr ,xmeye nvr ,dahua or other brand onvif nvr , onvif version is 2.6

Specification:





1/2.9" 4MP Low Lux CMOS sensor with Fullhan 2K DSP, single layer ; H.265+H.264 video coding, Support body detection & mark human frame,Main stream is 2560*1440,Sub stream is D1, Enabled with ONVIF protocol and NETCOM. With 0.5T Algorithm ,more accurate with human recognition.
Model  No.
Hardware
Module		Fullhan 2K DSP+1/2.9"4MP CMOS
LUX		Color 0.05Lux@F1.2; Black & White 0.005Lux@F1.2;
S/N		≥50db(AGC OFF)
WDR		DWDR;＞80db
Port
Audio Input		NA
Audio Output		NA
Light Type		NA
IO Function		1CH RESET
Video Coding
Coding Format		H.265,H.264
Resolution	Main Steam	2560*1440,1-25fps/s
		2304*1296,1920*1080,1280*720,1-30fps/s
	Sub steam	704*576,640*480,640*360,352*288,1-30fps/s
Video Coding Compression		128Kbps-8192bps continuous adjustable
Subtitle Overlay		Support Channel Name, Date & Time, Resolution & 4 lines characters adding
Data Transmission &Storage
DataRecord		Video,picture
Storage Method		Cycling Recording, Alarm Recording
Alarm Transfer		IO output, browser, management software
Protocol		ONVIF
Browser		Support IE6.0 and above browser(insert Web Server)
Mobile		Support  IOS,Android Platform
Comment Features
Temperature		-30℃ - +60℃
Humidity		0% - 90%
Power		DC12V / 110mA
Consumption		1.3W
Dimension		/
Weight		100g
